Product Description

The TE-12 features a simple and highly reliable design, the result of years of experience in the field. Weighing only 12.3kg (27.1lbs) yet supporting payloads up to 90kg, the TE-12 impressive weigh-to-payload ratio has made it an extremely popular with studio and OB camera crews alike.

Perfect balance through self-aligning rollers and Shotoku precision cam mechanisms means payload centre of gravity height remains constant throughout tilt operation making even the heaviest payloads effortless to control.

Unique to the head is the Shotoku cam protection function. Using this system, cams can be safely and quickly exchanged even with a camera, lens, and accessories on the head throughout the procedure.

Find a Dealer

Specifications

Max. Payload
90kg / 198.4lbs
Pan / Tilt Range
360° / ± 62.5°
Platform Adjustment
Forward 70mm / 3" Backward: 135mm / 5"
Counterbalance
Reulaux Perfect Balance Centre of Gravity Height: Constant
Drag
Viscam Continuously Adjustable Fluid-Leaf System
Temperature Range
-40° to +60°
Camera Fixing
V-Wedge (TA-74)
Suitable Pan Bar
TJ-38D, TJ-38E, TJ-59, TJ-60
Bubble Level
Illuminated
Weight
12.3kg / 27.1lbs
Mount
M70 Mitchell
Suitable Tripod / Pedestal
TT-17, TT-64, TP-80, TP-90, TP200
