Product Description

The TP200 pedestal is ideal for studio operations where light to medium payloads are in use and where exceptional on-air control is demanded at all times. Air balanced, TP200 height control is smooth, silent, and effortless across its entire stroke range. With an ergonomically designed steering ring and large, stable base, the pedestal is easily and comfortably maneuvered within studios. Colored positive action crab/steer foot-pedal and parking brake make control of any setup intuitive and easy.
Other features such as a simple slide adjust cable guard management system, easy-access wheel cleaning windows, integrated trim weight storage, and the ability to add air using only a hand-operated air pump make the TP200 the perfect choice for studios everywhere.

Specifications

Max Payload
80kg / 176.3lbs
Max Height
1,460mm / 57.5"
Min Height
690mm / 27.2"
On-Shot Stroke
770mm / 30"
Tracking Width
1,015mm / 40"
Transit Width
898mm / 35"
Weight
2kg / 202.8lbs (including trim weights)
Ground Clearance
1~23mm / 0.04"~0.9"
Wheel Diameter
130mm / 5"
Steering Ring Diameter
660mm / 26"
Individual Trim Weight (x6)
0.6kg / 1.3lbs
Mount
4-Bolt Flat Base
Suitable Heads
SG900, TE-23, TE-12, SX300
