SE150 Aluminum Tripod Systems

Share
Facebook
Twitter
LinkedIn

Product Description

10 Levels of Counterbalance | 16kg. Max Payload —

Shotoku SE150 systems provide high functionality and application flexibility designed for the extended range of camera systems available today. These systems feature a high-quality drag system to ensure smooth on-air moves and a multi-level counterbalance system to ensure accurate balancing of a wide range of cameras.

The SE150 supports up to 16kg (35 lbs) and has 10 levels of counterbalance and 6 grades of drag. The system comes complete with an aluminum 2 stage tripod, mid-level spreader or ground-level spreader, and a soft carrying case. A dolly option is available.

SE150 – A2G System

  • SE150 head
  • Single, fixedーlength pan bar
  • 2-stage aluminum tripod
  • Ground-level spreader
  • Soft carry case

SE150 – A2M System

  • SE150 head
  • Single, fixedーlength pan bar
  • 2-stage aluminum tripod
  • Midーlevel spreader with footpads
  • Soft carry case
Find a Dealer

Key Features

  • 10 levels of counterbalance
  • 6 grades of drag
  • Two systems to choose from based on performance needs
  • Head, fixed-length pan bar, tripod, spreader (mid-level or ground-level), and soft carrying case included
  • Dolly option available

Specifications

Max. Payload
16kg /35.3lbs
Optimum Payload Range
2kg ー 14kg / 4.4lbs ー 30.8lbs
Pan Range
360°
Tilt Range
+80° ~ ー75°
Counterbalance
10 Steps
Pan and Tilt Drag
6 Steps (5 + 0)
Camera Fixing
TwoーWay sliding quickーrelease plate with 2x3/8” screw
Pan Bar
Single, Fixed-Length
Mount
100mm Ball
Temperature Range
ー40°C to 60°C / ー40°F to 140°F
Level
Illuminated Bubble
Weight
SE150 - A2G System: 8.5kg / 18.7lbs SE150 - A2M System: 8.5kg / 18.7lbs
