Product Description

Perfect Counterbalance | 6 Configurations | 25kg Max. Payload —

Raising the bar on movement quality and shot framing control, comes the Shotoku SX260 ENG Support systems. The SX260 features a brand new ground-up design delivering the highest quality system from Shotoku’s manufacturing plant in Japan. The design concept for the new system was not only to create a product with best-in-class features and performance but to ensure it was robust, reliable, and one of the lightest on the market at this level of payload and performance. The new perfect counterbalance system, Shotoku Truebalance, delivers perfect counterbalance, is remarkably easy to adjust from one end of the range to the other, and has an intuitive display to indicate the current setting within the balance range. The drag system uses Shotoku’s well-known Viscam system but combines the ease and speed of selection of the best known stepped systems, with the fine-tuning and on-shot adjustment of a continuously variable design.

These 2 core features set the performance apart from the competition. Partnered with a new 100mm ENG Carbon Fibre tripod with fast action de-tented leg locks and mid or ground-level spreaders, the system delivers one of the lightest ENG systems available with a performance poised to set the new support standard for high-end ENG and EFP cameras.

SX260 features a payload of up to a maximum of 25Kg (55lbs) so is suitable for EFP, documentary, and sports applications with longer portable lenses. It can be partnered with the new 100mm bowl EFP tripod for maximum stability and enhancement of the counterbalance and drag features, or with the ENG tripod to provide an extremely lightweight EFP payload system.

Find a Dealer

Key Features

  • Available in ground-level spreader, mid-level spreader, or dolly configurations
  • Choose between the all new robust EFP tripod (TTH1002C) or extremely light ENG tripod (TTM1002C)

Specifications

System Contents
SX260 TTH1002C ML System — SX260 head including single telescopic pan bar + TTH1002C heavy-duty EFP two stage carbon fiber tripod + TML150 mid-level spreader with foot pads + TS150L semi-hard case SX260 TTH1002C GL System — SX260 head including single telescopic pan bar + TTH1002C heavy-duty EFP two stage carbon fiber tripod + TGL150 heavy-duty ground spreader + TS150L semi-hard case SX260 TTH1002C DOL System — SX260 head + two TJ-74 telescopic pan bars + TTH1002C heavy-duty EFP two stage carbon fiber tripod + TD-73 studio dolly SX260 TTM1002C ML System — SX260 head including single telescopic pan bar + TTM1002C ENG two stage carbon fiber tripod + TML150 mid-level spreader with foot pads + CSD100 soft carrying case SX260 TTM1002C GL System — SX260 head including single telescopic pan bar + TTM1002C ENG two stage carbon fiber tripod + TGL100 lightweight ground spreader + CSD100 soft carrying case SX260 TTM1002C DOL System — SX260 head + two TJ-74 telescopic pan bars + TTM1002C ENG two stage carbon fiber tripod + TD-73 studio dolly
Max. Payload
25kg / 55lbs
Optimum Payload Range
8 ~ 18.5kg / 17.7 ~ 40.7lbs
Pan / Tilt Range
360° / ±90°
Counterbalance
Continuously Adjustable Perfect Balance
Drag
Viscam Continuously Adjustable Fluid-Leaf System
