Product Description

Sporting our patented Reulaux perfect balance system, the SG900 achieves perfect balance and effortless control over an incredibly wide range of payloads. In contrast to spring-balanced systems, the Reulaux system features the added benefit of maintaining a constant height throughout the tilt range meaning the camera optical center never changes. This is because of the Reulaux design unique roller system which keeps the head’s center of gravity constant. Balance is adjusted by turning the counterbalance knob located near the camera operator, along with all other key controls such as locks and drag adjusters.

The SG900 supports up to 90kg (198.4lbs) and is ideal for all Studio and OB setups including heavy box lenses with teleprompters and talent monitors. The head also features VISCAM drag technology, our unique continuously adjustable fluid drag system, making every pan and tilt motion silky smooth from start to finish

Find a Dealer

Specifications

Max. Payload
90kg / 198.4lbs
Pan / Tilt Range
360° / +/-60°
Platform adjustment
Forward: 63mm / 2.48" Backward: 17mm / 0.67"
Counterbalance
Reulaux Perfect Balance
Drag
Viscam Continuously Adjustable Fluid-Leaf System
Temperature Range
-40° to +60°
Camera Fixing
V-Wedge (TA-74)
Suitable Pan Bar
TJ-38D, TJ-38E, TJ-59, TJ-60
Bubble Level
Illuminated
Weight
18.5kg / 40.7lbs
Mount
4-Bolt Flat Base or M70 Mitchell
Suitable Tripod/Pedestal
TT-17, TT-64, TP-80, TP200
