SE80

Share
Facebook
Twitter
LinkedIn

Product Description

The Shotoku SE range has evolved from a concept of providing high functionality and application flexibility in a support system designed for the extended range of camera systems available today. It features a high quality drag system to ensure smooth on air moves and a multiple level counterbalance system to ensure accurate balancing of a wide range of cameras.

The SE80 supports up to 10kg ( 22 lbs ) and has 8 levels of counterbalance and 4 grades of drag. The system comes complete with an aluminum or carbon fiber 2 stage tripod, mid or ground level spreader and a soft carrying case. A dolly option is also available.

SE80 – A2G System

SE80 head + single fixedーlength pan bar + 2 stage aluminum tripod + floor spreader + soft carrying case.

SE80 – A2M System

SE80 head + single fixedーlength pan bar + 2 stage aluminum tripod + mid-level spreader + soft carrying case.

SE80 – C2G System

SE80 head + single fixedーlength pan bar + 2 stage carbon fiber tripod + floor spreader + soft carrying case.

SE80 – C2M System

SE80 head + single fixedーlength pan bar + 2 stage carbon fiber tripod + mid-level spreader + soft carrying case.

FEATURES

・Lightweight

・Robust

・Smooth Operation

・Reliability

Find a Dealer

Specifications

Max. Payload
10kg / 22lbs
Optimum Payload Range
1kg ー 8kg / 2.2lbs ー 17.6lbs
Pan Range
360°
Tilt Range
+85° ~ ー75°
Counterbalance
8 Steps
Pan and Tilt Drag
4 Steps ( 3 + 0 )
Camera Fixing
Twoーway sliding quick release plate with 1 x 1/4” screw + pin and 1x 3/8” screw
Pan Bar
Single, FixedーLength
Mount
75mm Ball
Temperature Range
ー40°C ー 60°C / -40°F ー 140°F
Level
Bubble
Weight
1.95kg / 4.3lbs
